New kwh energy meter electricity utility 120/240V 100A
KWH Energy Meter Electricity Utility 120/240v 100A NEW!
•• NEW!!-This is a revolutionary meter at an extraordinary price!!!
•• State of the art, solid-state, digital energy meter
•• Compact, easy-to-install design
•• Monitor all critical circuits in your home or business
•• Pulse output-800 pulses per kWh
•• Not available anywhere else!! This is a TOTALLY unique product!
•• Optional**Watertight enclosures available
This is a brand new kWh meter design, manufactured for EKM Metering, the most advanced type electronic KWH meter available on the market, model EKM-25IDS, 3 wire, 100 amp version. These were made specifically for U.S. 3-wire 120/240 (range: 84-168/156-312) volt single phase (2 phase) metering. They require 156 to 312 volts for operation. Installation is easy, since the meter is completely self contained, no external current transformers (CT's) or other extras as with many other electronic type meters. However, installation should only be performed by a knowledgeable, qualified electrician. The 2 "hot" service wires are simply passed through tubes in the meter housing (3/8" diameter), and 2 screws are tightened to pierce the wiring to power the meter-less than 1 watt required. Installation and instruction manual included. Dimensions are approx. 3"w x 4"h x 2.5"d.
The meters have a non-resetable, 5 digit LCD readout with hundredths, and read directly in kWh, no conversion factors as with some other electronic meters. They have a built-in PULSE OUTPUT, 800 pulses per kWh. They are perfect for remote and automatic meter reading (AMR) applications.
Use these meters to measure and keep track of kilowatt hours and energy usage for sub panels or individual pieces of equipment. I can supply any number of these you need.
Also available in 120 volt version and in a "Smart" version-with RS-485 serial communication and on-board data storage.
If you need other types of kWh meters-
120 volt models, "Smart" meters with built-in data communication,
or external current transformer models,
please take a look at my other items for sale!
100% Satisfaction Guaranteed!! Return within 30 days if you are not completely satisfied. One year warranty from the manufacturer.
