11.0592MHZ hc-49/us, leaded crystals, at cut 20PF 20PCS
SERIES: HC-49/US / FREQ: 11.0592MHz
AT CUT, FUNDAMENTAL, 20PF LOAD CAPACITANCE
STANDARD AT CUT FUNDAMENTAL 3.5MM TALL HC-49 CRYSTAL
COMES WITH MICA INSULATOR, ISOLATES CRYSTALS CASE FROM PCB
BRAND NEW PARTS WHICH ARE BULK PACKED IN ESD SAFE BAG
SELLING 20EA 20PC LOTS INDIVIDUALY!
Image Hosted by VDB Engineering Inc. http:// .com
UP FOR SALE HERE IN MY STORE ARE 20EA 20PC LOTS OF A 11.0592MHz HC-49/US 3.5MM TALL LEADED HC-49 CRYSTAL. CRYSTALS HAVE 20PF LOAD
CAPACITANCE AND ARE AN AT FUNDAMENTAL CUT PART. THEY ALSO COME WITH A MICA INSULATOR THAT ISOLATES THE CRYSTALS BODY FROM
THE PCB. THIS PIECE OF MICA CAN BE REMOVED BY HAND TO INSURE THAT THE XTAL'S BODY CONTACTS THE PCB'S GROUND PLANE IF REQUIRED.
POPULAR MPU'S TO GENERATE THE NEEDED FREQUENCIES FOR BAUD RATE GENERATION FOR SERIAL COMMUNICATIONS ELSE THE GENERATED
SERIAL TRANSMISSIONS HAVE TO ALL BE DONE IN SOFTWARE VS HARDWARE WHEN THESE CRYSTALS ARE USED.
THANKS FOR LOOKING AND GOOD LUCK!
