Marathon 1413400 3-pole 600V distribution power block
This listing is for a SCCR power distribution / splicer block.
* Make: Marathon Special Products (a Regal-Beloit Company)
* Cat / Model / Part #: 1413400
___________________________________________________________________________________
Here is some information from the manufacturer...
Standard Power Distribution Blocks With High Short-Circuit Current Ratings
Marathon offers 600 Volt Power Distribution Blocks with high SCCR’s in response to new 2005 NEC R and UL508A marking requirements
* The requirements of the 2005 National Electric Code (NEC) and UL508A now require many electrical panels to carry a Short Circuit Current Rating (SCCR). Analyzing the SCCR of individual components and overcurrent protection devices is a method of determining the SCCR of an electrical assembly.
* Marathon’s Power Distribution Blocks are standard products that have been used in electrical control panels for over 35 years. These blocks have now been tested and approved for higher SCCR. The higher ratings are based on proper wire sizes and the appropriate circuit protection device.UL508A does allow default SCCR for Power Distribution Blocks of 10,000A with no additional testing.
* Marathon’s Power Distribution Blocks (UL File # E62806) are recognized under UL Standard 1059 and have been investigated by UL for Short- Circuit Current Ratings (SCCR) as described in the UL Guide Information for category XCFR2; Terminal Blocks-Component.
* (LINE) Rated Wire Range - (openings) kcmil/AWG: (1) 2 - 14
* (LOAD) Rated Wire Range - (openings) kcmil/AWG: (4) 10 - 16
For further details, please visit Marathon's catalog page at http:// /SCCR%20Power%20Blocks%20Flyer.pdf
___________________________________________________________________________________
This is brand new. Original packaging not included. Guaranteed to be in proper working order.
Check out the picture for more information. Feel free to ask any questions. WANT TO REACH ME BY PHONE? Feel free to call me (Trent) toll free (***) 972-1346.
