Radio design labs st-LCR1 stick-on logic control relay
Radio Design Labs ST-LCR1 STICK-ON Logic Controlled Relay
Radio Design Labs ST-LCR1 STICK-ON Logic Controlled Relay ,PRICE FOR 1PCS=$34.9, AVAIABLE =1 PCS
The ST-LCR1 provides double-pole, double-throw dry switching contacts and LED indicator for relay closure. The ST-LCR1 provides momentary operation and is ideally suited where additional switching contacts are needed to be added to nearly any type of control signal.
* More Contacts by Adding a Slave Relay
* Activation from Logic Circuits
* Control from Switch, Button or Logic Circuits
SLAVE terminal used as an input from remote push-button or switch turns on relay when that switch is on. Activation is by connecting this input to Ground. Input from other equipment’s open-collector output turns relay on when open-collector is on.
Note: RDL® switching STICK-ONs® have open-collector outputs suitable for driving an ST-LCR1.
5V+ accepts 3.5 to 12 Vdc to turn on relay. Relay is on only when this control signal is applied.
24V+ accepts 12 to 35 Vdc to turn on relay. Relay is on only when this control signal is applied.
* Control Output: SLAVE terminal open-collector @ 50 mA suitable to drive indicators or slave LCRs
* Switching Contacts: Double-pole, double-throw
* Max. Switching Power: 60 W, 125 VA
* Max. Switching Voltage: 220 Vdc, 250 Vac
* Max. Switching Current: 2 A
* Max. Carrying Current: 3 A
* Power Requirement: GROUND-REFERENCED, 24 to 33 Vdc @ 50 mA *
* Assumes 20 mA max load at SLAVE output
