Hewlett packard hp 8503B s-parameter test meter 75 ohms
Hewlett Packard HP 8503B S-Parameter Test Meter 75 Ohms
The HP Agilent 8503B is a used 75 ohm, 1.3 GHz, S Parameter Test Set
Due to its wide frequency range of 500kHz to 1.3GHz and directivity of >/=40 dB
The Agilent HP 8503B S-Parameter Test Set is considered one of the best in the industry
Transmission (S1, S2): ±1 dB, ±12º from 0.5 to 1300MHz
Reflection (S1, S2): ±2 dB, ±20º from 0.5 to 1300MHz): ±15º from 2 to 1300MHz.
Maximum operating level of ±20 dBm
Connectors: Test ports, 75 ohm APC-7, all other RF connectors, 75 ohm Type N(F); bias inputs, BNC female
DC bias input: ±30 VDC, ±200 mA
Local Pick up is also available at our office in Clayton South VIC 3169 with 24 Hrs Prior Notice.
Building Trust in Transactons (tm)
If you have any questions please contact Lily or
Phone (switch) +613 9558 0004 Ext : 138
Office Hours are 9.00AM - 5.00PM
